DIMM Slots:4, DDR5 only

Max Memory Support:128GB, DDR5

Memory Architecture:Dual-Channel

OC Frequency:6000+(O.C.). Please refer to memory QVL.

Intel® Extreme Memory Profile (XMP) 3.0:Supported

PCIe 5.0 ×16 slot (PCIEX16_1), supports ×16 mode:1 (Supports NVMe SSD as boot disks)

PCIe 4.0 ×16 slots (PCIEX16_2 and PCIEX16_3), support ×4 mode:2 (Supports NVMe SSD as boot disks)

PCIe 3.0 ×1 slots (PCIEX1_1 and PCIEX1_2)*:2 (Supports NVMe SSD as boot disks)

M.2 Socket (Key E), supports Type 2230 Wi-Fi/BT PCIe Wi-Fi module and Intel® CNVio/CNVio2:1

 M.2_1, Type 2242/2260/2280 (PCIe 4.0 ×4 mode):1

M.2_2, Type 2242/2260/2280/22110 (PCIe 4.0 ×4 mode):1

M.2_3, Type 2242/2260/2280 (PCIe 4.0 ×4 and SATA 6Gb/s mode):1

SATA 6Gb/s ports:4

Intel® Volume Management Device (VMD):Supported

NVMe SSD as boot disks:Supported

8+4-pin ATX 12V power connector:1

4-pin CPU_FAN connector:1

4-pin AIO_PUMP connector:1

4-pin SYS_FAN connectors:5

NZXT RGB LED connectors:4

5V ARGB LED connector:2

USB 2.0 header (Up to 4 USB 2.0 ports):2

USB 3.2 Gen1 header (Up to 2 USB 3.2 Gen 1 ports):1

USB 3.2 Gen2x2 front panel header (For USB Type-C):1

Front panel audio connector:1

Power button:1

Reset button:1

POST LEDs:4

Wireless antenna SMA connectors:2

HDMI™ port:1

USB 2.0:2

USB 3.2 Gen 2x2 Type-C port:1

USB 3.2 Gen 2 ports:2

USB 3.2 Gen 1 ports:3

Clear CMOS button:1

LAN (RJ45) port:1

Audio jacks:5

Optical S/PDIF Out port:1
