Thương hiệu

MSI

CHIPSET

AMD B450

CPU

Socket AM4

MEMORY

2x DDR4, Maximum Memory Capacity 64GB

ONBOARD GRAPHICS

1x HDMI™

Support HDMI^TM 2.0b, maximum resolution of 4K 60Hz*

1x DVI

Support DVI-D, maximum resolution of 1920x1200 60Hz

SLOT

1x PCI-E x16 slot

1x PCI-E x1 slot

PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 2.0 supports up to x1 (From Chipset)

STORAGE

1x M.2

M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices

4x SATA 6G

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

USB

2x USB 2.0 (Rear)

4x USB 2.0 (Front)

4x USB 3.2 Gen1 Type A (Rear)

2x USB 3.2 Gen1 Type A (Front)

LAN

Realtek^® 8125 2.5Gbps LAN controller

AUDIO

Realtek^® ALC897 Codec

7.1-Channel High Definition Audio

INTERNAL IO

1x Power Connector(ATX_PWR)

1x Power Connector(CPU_PWR)

1x CPU Fan

1x System Fan

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Front Audio (JAUD)

1x Com Port (JCOM)

1x TPM pin header(Support TPM 2.0)

4x USB 2.0 ports

2x USB 3.2 Gen1 Type A ports

BACK PANEL PORTS

Keyboard/Mouse

DVI-D

HDMI™

USB 3.2 Gen 1 5Gbps (Type-A)

2.5G LAN

Audio connectors

USB 2.0

PCB INFO

mATX
200mmx236mm
